Coil Size Cutting Machine
Data sheet
| Unwinder Bobbin Diameter | 1600 mm |
| Knife Size | 1230 |
| Idler roller width | 1250 mm |
| Cutting system | Servo motor |
| Knife system | Upper blade movable, lower blade fixed |
| Cut length | 400 mm / 1450 mm |
| Pneumatic pressure requirement | min. 6 Bar |
| Cutting Sensitivity | ±0,25 mm |
| Paper and Cardboard Grammage | 40 gr/ 500 gr |
| Tension Control | AVAILABLE |
| Web Guide | AVAILABLE |
| Circular Knife Slicer | 3 blades, 2 combined |
| Elevator height | 1300 mm |
| Elevator system | Automatic and manual system |
| Unwinder | 1- 2 and 4 bobbin uninder cuts |
| Unwinder Type | shaftless |
| Working Voltage | 380 |
| Color | Ral series |
